MAIN TECHNICAL ITEM

DETAILS

MODEL

SD-P-W588

WARP YARN FEEDING

YARN FEEDING FROM REELS FROM GROUP OF YARN STAND

CLOTH TAKE-UP

1. ELECTIRC TAKE-UP WITH AUTO CHANGE PICK DENSITY FUNCTION

2. JUMBO ROLL WITH TORQUE MOTOR ROLL DIAMETER UPTO 1000mm, CAPABLE TO ROLL 9000-12000m CLOTH, WEIGHT UPTO 12000KGS

WEFT YARN FEEDING

ELECTRIC FEEDER

MESH RANGE

4*4~30*30

YARN RANGE

40D-2000D

DAILY PRODUCTIVITY

2000~3500m

WEAVING WIDTH

150~360cm

MAIN MOTOR

1. 1.8kw FOR MACHINE WIDTH BELOW 230cm

2. 2.5kw FOR MACHINE WIDTH: 260cm

3. 2.8kw FOR MACHINE WIDTH: 280~360cm

SPEED

500~750RPM

OUR SD-P-W588 SERIES WEAVING MACHINE IS MODIFIED TO WEAVE DIFFERENT TYPES OF PLASTIC PRODUCTS LIKE TARPAULIN, BARSATIC PLASTIC AND THE LIKES; IT’S FEATURED TO WEAVE HIGH-DENSITY WOVEN CLOTH LIKE TARPAULIN AT HIGH SPEED, WHICH WILL BE USED FOR PACKING USE. AND CLOTH WOVEN ON OUR MACHINE IS WITH A SHINNING AND SMOOTH SURFACE.
